edp E100 box filler
High Capacity carton and RPC filling unit
Features:
- Capacity 15-22kilo single dump.
- Fill rate up to 15 BPM.
- Dual vibrative fill.
- Capable of working off any weigher.
- Full Stainless Steel construction

Features
- Robust #304 Stainless Steel Construction.
- Capacity of 15-22kg in a single discharge.
- Fill Rate of up to 15 Boxes /Trays per minute.
- Capable of working with any type of weigher.
- Vibrating Belt on Filling Position & Vibrating Belt on Discharge Position.
- Gentle delivery of product into the box / tray.
- Multiple weight recipes can be stored in the PLC for easy product changeover.
- 7” HMI Screen for ease of operation.
- Remote Connectivity for Remote Assistance and Support.
- Left and Right Hand Variants available.
Specifications
Power Requirement: 3 x 0.18kW & 2 x 0.25kW
Air Requirement: 20ltrs / minute @ 6Bar
Weight: 545 KG’s
Dimensions: 2490mm L x 600mm W x 2700mm H
Capacity: Up to 15 boxes / trays per Minute

Reliable and Renowned
An original equipment manufacturer, edp has a well established export market as well as strong associations with European manufacturers to offer the best technology in the world of fresh produce packaging and handling equipment.
