edp SOFT BIN TIPPER

  • Ideal for delicate fruit such as apples & mandarins
  • Available in various models including fully automatic with auto bin feed entry and exit.

The bins can be loaded into the machine with pallet truck or fork lift. The bin is unloaded via an exit belt, a photoelectric eye controls unloading of the fruit. A discharge brush prevents damage to the fruit on exit.

Bin Dimensions: 1000×1000 – max 1200×1200 h= 550 to 780 – max weight 600kg

The tipper is powered by hydraulics and is very simple in design. The unit is controlled via data entry keyboard.

The bin is completely inverted and moves forward as it empty’s.

overall dimensions

Width:
2100mm

Length:
2000mm

Height:
2100mm

Weight:
600kg

Reliable and Renowned

An original equipment manufacturer, edp has a well established export market as well as strong associations with European manufacturers to offer the best technology in the world of fresh produce packaging and handling equipment.
