edp SOFT BIN TIPPER
The bins can be loaded into the machine with pallet truck or fork lift. The bin is unloaded via an exit belt, a photoelectric eye controls unloading of the fruit. A discharge brush prevents damage to the fruit on exit.
The tipper is powered by hydraulics and is very simple in design. The unit is controlled via data entry keyboard.
The bin is completely inverted and moves forward as it empty’s.
SPECIFICATIONS
Width: 2100mm
Length: 2000mm
Height: 2100mm
Weight: 600kg
- Ideal for delicate fruit such as apples & mandarins
- Available in various models including fully automatic with auto bin feed entry and exit.
Reliable and Renowned
An original equipment manufacturer, edp has a well established export market as well as strong associations with European manufacturers to offer the best technology in the world of fresh produce packaging and handling equipment.
edp
edp is a leading Australian supplier of fresh fruit and vegetable grading & packaging solutions including machinery and consumables.
